- ULTRA-COMPACT and perfect balance at only 116 mm long for maximum control and maneuverability
- Rigid anvil retention for reduced bit wobbling
- Power selection switch provides the user with precise fastening control for a wide range of applications
- Convenient one-touch 6.35 mm (1/4″) hex chuck for quick bit changes (for some countries only)
- Battery protection circuit protects against overloading, over-discharging and over-heating
- Electric brake for maximum productivity and increased operator safety
- Easy-to-operate, push button type F/R change switch
Specification：
| Capacity | Machine Screw: M4 – M8 (5/32″ – 5/16″) Standard Bolt : M5 – M16 (3/16″ – 5/8″) High Tensile Bolt: M5 – M14 (3/16″ – 9/16″) Coarse Thread (in length): 22 – 125 mm (7/8″ – 4-7/8″) |
| Hex Shank | 6.35 mm (1/4″) |
| Fastening Torque | Med: 50 N·m (440 in.lbs.) |
| Impacts Per Minute (IPM) | Max: 0 – 3,800 | Hard: 0 – 3,600 | Med: 0 – 2,600 | Soft: 0 – 1,100 | Wood: 0 – 3,800 | Bolt: 0 – 3,800 | T(1) mode: N/A | T(2) mode: 0 – 2,600 |
| No Load Speed (RPM) | Max: 0 – 3,600 | Hard: 0 – 3,200 | Med: 0 – 2,100 | Soft: 0 – 1,100 | Wood: 0 – 1,800 | Bolt: 0 – 3,600 | T(1) mode: 0 – 2,900 | T(2) mode: 0 – 3,600 |
| Max Fastening Torque | 180 N·m (1,590 in.lbs.) |
| Dimensions (L x W x H) | 116 x 79 x 236 mm (4-9/16″ x 3-1/8″ x 9-1/4″) |
| Net Weight | 1.2 – 1.6 kg (2.7 – 3.4 lbs.) |
| Work Amount | 808 pcs with BL1850B Coarse Thread Screw 65 mm |
Standard equipment:
- Belt Clip
Available options:
- RTJ: 1x Rapid Charger, 2x 5.0Ah Battery, 1x Makpac Connector Box
- RFJ: 1x Rapid Charger, 2x 3.0Ah Battery, 1x Makpac Connector Box
- Z: Without Charger, Battery & Carrying Case
