- ULTRA-COMPACT and ergonomic design at only 117 mm long
- Dual LED lights with preglow and afterglow functions illuminate the work area more widely
- BL motor efficiently uses energy to match torque and RPM to the changing demands of the application
- Extreme Protection Technology (XPT) is engineered for improved dust and water resistance for operation in harsh conditions
- Electric brake for maximum productivity and increased operator safety
Specification:
| Capacity | Machine Screw: M4 – M8 (5/32″ – 5/16″) Standard Bolt : M5 – M16 (3/16″ – 5/8″) High Tensile Bolt: M5 – M14 (3/16″ – 9/16″) Coarse Thread (in length): 22 – 125 mm (7/8″ – 4-7/8″) |
| Impacts Per Minute (IPM) | 0 – 3,800/0 – 2,600/0 – 1,100 |
| No Load Speed (RPM) | 0 – 3,600 | 0 – 2,100 | 0 – 1,100 |
| Max Fastening Torque | 175N·m (1,550in.lbs.) |
| Dimensions (L x W x H) | 117 x 79 x 236 mm (4-5/8″ x 3-1/8″ x 9-1/14″) |
| Net Weight | 1.3 – 1.6 kg (2.8 – 3.5 lbs.) |
| Work Amount | 800 pcs with BL1850B Wood Screw Ø4.3 x 65 mm |
Standard equipment:
- Belt Clip
Available options:
- RME: 1x Rapid Charger, 2x 4.0Ah Battery
- RFE: 1x Rapid Charger, 2x 3.0Ah Battery
- Z: Without Charger, Battery & Carrying Case
