- Indication lamp using ADT (Automatic torque Drive Technology)
- High-efficiency BL motor provides higher power and more work amount
- Blower function blows sawdust off the cut line ahead for a better cutting view
- Dual LED job lights with preglow and afterglow functions for more visibility
- Electric brake for maximum productivity and increased operator safety
Specification:
| Max Output | 680 W |
| Hole Diameter | 15.88 mm (5/8″) | 20 mm (13/16″) |
| Blade Diameter | 165 mm (6 – 1/2″) |
| Max Cutting Capacity | 90°: 57 mm (2-1/4″) 45°: 41mm (1-5/8″) 50°: 37 mm (1-7/16″) |
| No Load Speed (RPM) | 5,000 |
| Dimensions (L x W x H) | 270 x 186 x 250 mm (10-5/8″ x 7-3/8″ x 9-7/8″) |
| Net Weight | 2.9 – 3.2 kg (6.4 – 7.1 lbs.) |
| Work Amount | 200 pcs with BL1850B Sawing with EFFICUT blade, 90° cut SPF 2 x 10 (Thickness 38mm, Width 89mm) |
Standard equipment:
- TCT Saw Blade (B-63018), Hex Wrench, Rip Fence (Guide Rule), Dust Nozzle
Available options:
- RFJ: 1x Rapid Charger, 2x 3.0Ah Battery, 1x Makpac Connector Box
- Z: Without Charger, Battery & Carrying Case
