- All ball and needle bearings for longer life
- Built-in thickness gauge for operator convenience
- Easy punch and die replacement for less down time
- Lock-On Button enables easy continuous operation
- Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Specification:
| Continuous Rating Input | 710 W |
| Capacity | Steel up to 400 N/mm² : 3.2 mm Steel up to 600 N/mm² : 2.5 mm Steel up to 800 N/mm² : 1.0 mm Aluminum up to 200 N/mm² : 3.5 mm |
| Min Cutting Radius | Outside edge : 128 mm (5 – 1/16″) Inside edge : 120 mm (4 – 3/4″) |
| Strokes Per Minute (SPM) | 1,300 |
| Dimensions (L x W x H) | 225 x 90 x 254 mm (8-7/8″ x -1/2″ x 10″) |
| Net Weight | 3.4 kg (7.5 lbs.) |
| Power Supply Cord | 2.5 m (8.2 ft) |
Standard Equipment:
- Punch, Die, Wrench 50, Hex Wrench, Washer
