- Bevel-cuts up to 45 degrees
- Up to 125 mm (5″) diameter diamond wheel can be used
- Wide blade case enables use of diamond cup wheel
- Water supply plug; Plastic is used for lightweight design
- Leading edge of baseplate indicates precise line of cut
Specification:
| Continuous Rating Input | 1,400 W |
| Max Cutting Capacity w/ 110mm (4-3/8″) Wheel | 90°: 32.5 mm (1 – 1/4″) 45°: 21.5 mm (7/8″) |
| Max Cutting Capacity w/ 125mm (5″) Wheel | 90°: 40.0 mm (1 – 9/16″) 45°: 27.0 mm (1 – 1/16″) |
| Blade Diameter | Max 125 mm (Max 5″) |
| No Load Speed (RPM) | 12,200 |
| Dimensions (L x W x H) | 238 x 214 x 169 mm (9-3/8″ x 8-3/8″ x 6-5/8″) |
| Net Weight | 3.0 kg (6.6 lbs.) |
| Power Supply Cord | 2.5 m (8.2 ft) |
Standard Equipment:
- Wrench, Hex Wrench
