Vitali Geared Trolley
SKU:
KWD010B Vitali Geared Trolley 1 tonnes, 6m
Brand: Vitali
Category: Lifting, Lashing › Trolley
<img loading="lazy" decoding="async" class="alignnone size-medium wp-image-50426" src="/api/media/resolve?id=1475efc1-ea2f-43d0-9a17-a5a2a9f735ae&redirect=true" alt="" width="300" height="300" srcs...
RM346.20
Price range: RM346.20 - RM715.40
In Stock
Capacity
Quantity
Description
| Model | KWD010B | KWD020B | KWD030B | KWD050B | KWD100B | |
| Capacity | (t) | 1 | 2 | 3 | 5 | 10 |
| Proof Load | (t) | 1.5 | 3 | 4.5 | 7.5 | 15 |
| I-Beam Width | (mm) | 75-125 | 100-150 | 100-150 | 125-175 | 125-210 |
| Dimensions (mm) | A | 255.5 | 290.5 | 309 | 353 | 426.5 |
| B | 206 | 233 | 276 | 304 | 389 | |
| C | 145 | 176 | 207 | 237 | 306.5 | |
| D | 36 | 42 | 58 | 64 | 80 | |
| E | 20.2 | 28.5 | 27.5 | 32 | 38 | |
| Min. Radius Curve | (m) | 1 | 1.1 | 1.3 | 1.4 | 1.7 |
| Net Weight | (kg) | 12.2 | 18.8 | 28.9 | 43.4 | 83 |
Additional Information
Length
130 cm
Width
65 cm
Height
110 cm
Weight
14 kg
Specifications
No Specifications Available
Technical specifications have not been added yet.
| Model | KWD010B | KWD020B | KWD030B | KWD050B | KWD100B | |
| Capacity | (t) | 1 | 2 | 3 | 5 | 10 |
| Proof Load | (t) | 1.5 | 3 | 4.5 | 7.5 | 15 |
| I-Beam Width | (mm) | 75-125 | 100-150 | 100-150 | 125-175 | 125-210 |
| Dimensions (mm) | A | 255.5 | 290.5 | 309 | 353 | 426.5 |
| B | 206 | 233 | 276 | 304 | 389 | |
| C | 145 | 176 | 207 | 237 | 306.5 | |
| D | 36 | 42 | 58 | 64 | 80 | |
| E | 20.2 | 28.5 | 27.5 | 32 | 38 | |
| Min. Radius Curve | (m) | 1 | 1.1 | 1.3 | 1.4 | 1.7 |
| Net Weight | (kg) | 12.2 | 18.8 | 28.9 | 43.4 | 83 |
