FITOK Male Adapters (SAE/MS Straights (OST), Fractional Tube)
SKU:
Brand: FITOK
Category: Fittings and Accessories › Instrumentation Tube Fittings › Connectors
Tags: Fitok, Pipe Fitting, Connectors, Plumbing
FITOK Male Adapters — 316/316L stainless steel compression double-ferrule tube fittings (Fractional Tube, SAE/MS Straight Threads (OST)), FITOK 6D Series. Ordering numbers shown are FITOK's part-nu...
Contact us for pricing
This product requires a custom quote
Port 1 Size
Port 2 Size
Port 3 Size
Quantity
Description
FITOK Male Adapters — 316/316L stainless steel compression double-ferrule tube fittings (Fractional Tube, SAE/MS Straight Threads (OST)), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as published in FITOK's 6D dimensional catalog; the material/series prefix (e.g. 'SS-' for 316 stainless) is applied by FITOK at order entry and is not included in the source catalog data.
Available Variants & Specifications
| Ordering No. | Port 1 Size | Port 2 Size | Port 3 Size | L (Length) | B (Thread) | E (Min Orifice) | F (Body Hex) |
|---|---|---|---|---|---|---|---|
SS-AM-FT2-OST5 |
1/8 | 2 | 5/16-24 | 1.28(32.5) | 0.34(8.6) | 0.08(2.0) | 0.56(14.3) |
SS-AM-FT3-OST6 |
3/16 | 3 | 3/8-24 | 1.38(35.1) | 0.38(9.7) | 0.12(3.0) | 0.63(15.9) |
SS-AM-FT4-OST7 |
1/4 | 4 | 7/16-20 | 1.54(39.1) | 0.41(10.4) | 0.17(4.3) | 0.75(19.1) |
SS-AM-FT5-OST8 |
5/16 | 5 | 1/2-20 | 1.64(41.7) | 0.44(11.2) | 0.22(5.6) | 0.87(22.2) |
SS-AM-FT6-OST9 |
3/8 | 6 | 9/16-18 | 1.70(43.2) | 0.47(11.9) | 0.27(6.9) | 0.94(23.8) |
SS-AM-FT8-OST12 |
1/2 | 8 | 3/4-16 | 1.95(49.5) | 0.47(11.9) | 0.37(9.4) | 1.13(28.6) |
Additional Details
Instrumentation tube fitting for high-pressure, leak-tight, vibration-resistant connections in process, analytical, and instrumentation piping systems. Interchangeable in form, fit and function with other major compression tube fitting brands.
Additional Information
Length
6 cm
Width
4 cm
Height
4 cm
Weight
0.1 kg
Specifications
Material
316/316L Stainless Steel (Ni content >= 28.5%)
Connection Style
Compression, double-ferrule tube fitting (FITOK 6D Series)
Standard / Certification
Tested to ASTM F1387; dimensionally interchangeable with other major compression tube fitting brands
Pressure Rating
Rated to the maximum working pressure of the mating FITOK tubing (fitting is not the pressure-limiting component)
Thread Type
SAE/MS Straight Threads (OST)
Tube Type
Fractional Tube
Max working pressure
6000 psig psig
Operating temperature
-28 to +204 °C °C
FITOK Male Adapters — 316/316L stainless steel compression double-ferrule tube fittings (Fractional Tube, SAE/MS Straight Threads (OST)), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as published in FITOK's 6D dimensional catalog; the material/series prefix (e.g. 'SS-' for 316 stainless) is applied by FITOK at order entry and is not included in the source catalog data.
Available Variants & Specifications
| Ordering No. | Port 1 Size | Port 2 Size | Port 3 Size | L (Length) | B (Thread) | E (Min Orifice) | F (Body Hex) |
|---|---|---|---|---|---|---|---|
SS-AM-FT2-OST5 |
1/8 | 2 | 5/16-24 | 1.28(32.5) | 0.34(8.6) | 0.08(2.0) | 0.56(14.3) |
SS-AM-FT3-OST6 |
3/16 | 3 | 3/8-24 | 1.38(35.1) | 0.38(9.7) | 0.12(3.0) | 0.63(15.9) |
SS-AM-FT4-OST7 |
1/4 | 4 | 7/16-20 | 1.54(39.1) | 0.41(10.4) | 0.17(4.3) | 0.75(19.1) |
SS-AM-FT5-OST8 |
5/16 | 5 | 1/2-20 | 1.64(41.7) | 0.44(11.2) | 0.22(5.6) | 0.87(22.2) |
SS-AM-FT6-OST9 |
3/8 | 6 | 9/16-18 | 1.70(43.2) | 0.47(11.9) | 0.27(6.9) | 0.94(23.8) |
SS-AM-FT8-OST12 |
1/2 | 8 | 3/4-16 | 1.95(49.5) | 0.47(11.9) | 0.37(9.4) | 1.13(28.6) |
Additional Details
Instrumentation tube fitting for high-pressure, leak-tight, vibration-resistant connections in process, analytical, and instrumentation piping systems. Interchangeable in form, fit and function with other major compression tube fitting brands.
