- Battery Operated, Factory Calibrated Class II Laser enables accurate alignment of blade and cutting line
- Large Cutting Capacity in a Compact Design and Less Weight
- Linear ball bearing system engineered to deliver “dead-on” accurate cuts
- Rear handle bevel lock is easily accessible and adjusts 0° – 45° (left and right) with positive stops at 0°, 45° (left and right)
- See-through blade guard system for greater visibility of blade and line of cut
Specification:
| Continuous Rating Input | 1,430 W |
| Blade Diameter | 255 – 260 mm (10 – 10-1/4″) |
| Miter Angle | 47° L / 60° R |
| Max Cutting Capacity | 90°: 91 x 305 mm (3-5/8″ x 12″) |
| 45°: 91 x 215 mm (3-5/8″ x 8-1/2″) | |
| Bevel Angle | 45° L / 45° R |
| No Load Speed (RPM) | 4300 |
| Dimensions (L x W x H) | 825 x 536 x 633 mm (32-1/2″ x 21-1/8″ x 25″) |
| Net Weight | 20.6 kg (45.4 lbs.) |
| Power Supply Cord | 2.5 m (8.2 ft) |
Standard Equipment:
- TCT Saw Blade, Vertical Vise, Socket Wrench, Triangular Rule, Dust Bag, Holder assembly
