- Unique 2-Steel Rail Sliding System Design Allows Operation Flush Against a Wall
- Increased capacity for up to 203 mm (8″) crown molding (vertically nested), 171 mm (6-3/4″) baseboard (vertical), and 382 mm (15″) crosscuts at 90°
- Dual dust collection ports provide excellent dust extraction performance
- Integrated guide fences for increased rigidity and high cutting accuracy
- Single sliding system enables smooth operation to produce superior cuts
Specification:
| Continuous Rating Input | 1,800 W |
| Hole Diameter | European Countries: 30 mm (1 – 3/16″) |
| Others: 25.4 mm (1″) | |
| Angle | Bevel: 48° L | 48° R |
| Miter: 60° L | 60° R | |
| Blade Diameter | 305 mm (12″) |
| Max Cutting Capacity | Crown Molding Vertically Nested: 203 mm (8″) |
| Crown Molding Lying Flat: 320 mm (12 – 5/8″) | |
| Base Board Against Fence: 171 mm (6 – 3/4″) | |
| Base Board Lying Flat with auxiliary wood on base: 416 mm (16 – 3/8″) | |
| No Load Speed (RPM) | 3,200 |
| Dimensions (L x W x H) | 898 x 664 x 725 mm (35-1/4″ x 26-1/8″ x 28-1/2″) |
| Net Weight | 29.5 kg (65.0 lbs.) |
| Power Supply Cord | 2.5 m (8.2 ft) |
Standard Equipment:
- TCT Saw Blade, Vertical Vise, Hex Wrench, Triangular Rule, Dust Bag
