FITOK Male Adapters (37 Flare (AN), Fractional Tube)
SKU:
Brand: FITOK
Category: Fittings and Accessories › Instrumentation Tube Fittings › Connectors
Tags: Fitok, Pipe Fitting, Connectors, Plumbing
FITOK Male Adapters — 316/316L stainless steel compression double-ferrule tube fittings (Fractional Tube, 37 Flare (AN)), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as p...
Contact us for pricing
This product requires a custom quote
Port 1 Size
Port 2 Size
Quantity
Description
FITOK Male Adapters — 316/316L stainless steel compression double-ferrule tube fittings (Fractional Tube, 37 Flare (AN)), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as published in FITOK's 6D dimensional catalog; the material/series prefix (e.g. 'SS-' for 316 stainless) is applied by FITOK at order entry and is not included in the source catalog data.
Available Variants & Specifications
| Ordering No. | Port 1 Size | Port 2 Size | L (Length) | B (Thread) | E (Min Orifice) | F (Body Hex) |
|---|---|---|---|---|---|---|
SS-AM-FT12-AN12 |
3/4 | 3/4 | 2.21(56.1) | 0.86(21.8) | 0.58(14.7) | 1.13(28.6) |
SS-AM-FT16-AN16 |
1 | 1 | 2.58(65.5) | 0.91(23.1) | 0.80(20.3) | 1.37(34.9) |
SS-AM-FT4-AN4 |
1/4 | 1/4 | 1.46(37.1) | 0.55(14.0) | 0.17(4.3) | 0.50(12.7) |
SS-AM-FT6-AN4 |
3/8 | 1/4 | 1.53(38.9) | 0.55(14.0) | 0.17(4.3) | 0.50(12.7) |
SS-AM-FT6-AN6 |
3/8 | 3/8 | 1.56(39.6) | 0.56(14.2) | 0.27(6.9) | 0.63(15.9) |
SS-AM-FT8-AN8 |
1/2 | 1/2 | 1.91(48.5) | 0.66(16.8) | 0.37(9.4) | 0.81(20.6) |
Additional Details
Instrumentation tube fitting for high-pressure, leak-tight, vibration-resistant connections in process, analytical, and instrumentation piping systems. Interchangeable in form, fit and function with other major compression tube fitting brands.
Additional Information
Length
6 cm
Width
4 cm
Height
4 cm
Weight
0.1 kg
Specifications
Material
316/316L Stainless Steel (Ni content >= 28.5%)
Connection Style
Compression, double-ferrule tube fitting (FITOK 6D Series)
Standard / Certification
Tested to ASTM F1387; dimensionally interchangeable with other major compression tube fitting brands
Pressure Rating
Rated to the maximum working pressure of the mating FITOK tubing (fitting is not the pressure-limiting component)
Thread Type
37 Flare (AN)
Tube Type
Fractional Tube
Max working pressure
6000 psig psig
Operating temperature
-28 to +204 °C °C
FITOK Male Adapters — 316/316L stainless steel compression double-ferrule tube fittings (Fractional Tube, 37 Flare (AN)), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as published in FITOK's 6D dimensional catalog; the material/series prefix (e.g. 'SS-' for 316 stainless) is applied by FITOK at order entry and is not included in the source catalog data.
