FITOK Lapped Flange Connectors (NPT, Metric Tube)
SKU:
Brand: FITOK
Category: Fittings and Accessories › Instrumentation Tube Fittings › Flange & Weld Fittings
Tags: Fitok, Flange Fitting, Pipe Fitting
FITOK Lapped Flange Connectors — 316/316L stainless steel compression double-ferrule tube fittings (Metric Tube, NPT Thread), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix ...
Contact us for pricing
This product requires a custom quote
Port 2 Size
Quantity
Description
FITOK Lapped Flange Connectors — 316/316L stainless steel compression double-ferrule tube fittings (Metric Tube, NPT Thread), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as published in FITOK's 6D dimensional catalog; the material/series prefix (e.g. 'SS-' for 316 stainless) is applied by FITOK at order entry and is not included in the source catalog data.
Available Variants & Specifications
| Ordering No. | Port 2 Size | L (Length) | G (Nut Hex) | C (Depth) | E (Min Orifice) | J |
|---|---|---|---|---|---|---|
SS-LFC-ML10A |
A | 82.6(3.25) | 19.0(0.75) | 17.2(0.68) | 7.9(0.31) | 34.5(1.36) |
SS-LFC-ML10B |
B | 82.6(3.25) | 19.0(0.75) | 17.2(0.68) | 7.9(0.31) | 34.5(1.36) |
Additional Details
Instrumentation tube fitting for high-pressure, leak-tight, vibration-resistant connections in process, analytical, and instrumentation piping systems. Interchangeable in form, fit and function with other major compression tube fitting brands.
Additional Information
Length
6 cm
Width
4 cm
Height
4 cm
Weight
0.1 kg
Specifications
Material
316/316L Stainless Steel (Ni content >= 28.5%)
Connection Style
Compression, double-ferrule tube fitting (FITOK 6D Series)
Standard / Certification
Tested to ASTM F1387; dimensionally interchangeable with other major compression tube fitting brands
Pressure Rating
Rated to the maximum working pressure of the mating FITOK tubing (fitting is not the pressure-limiting component)
Tube Type
Metric Tube
Tube Size
10 mm
Max working pressure
6000 psig psig
Operating temperature
-28 to +204 °C °C
FITOK Lapped Flange Connectors — 316/316L stainless steel compression double-ferrule tube fittings (Metric Tube, NPT Thread), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as published in FITOK's 6D dimensional catalog; the material/series prefix (e.g. 'SS-' for 316 stainless) is applied by FITOK at order entry and is not included in the source catalog data.
Available Variants & Specifications
| Ordering No. | Port 2 Size | L (Length) | G (Nut Hex) | C (Depth) | E (Min Orifice) | J |
|---|---|---|---|---|---|---|
SS-LFC-ML10A |
A | 82.6(3.25) | 19.0(0.75) | 17.2(0.68) | 7.9(0.31) | 34.5(1.36) |
SS-LFC-ML10B |
B | 82.6(3.25) | 19.0(0.75) | 17.2(0.68) | 7.9(0.31) | 34.5(1.36) |
Additional Details
Instrumentation tube fitting for high-pressure, leak-tight, vibration-resistant connections in process, analytical, and instrumentation piping systems. Interchangeable in form, fit and function with other major compression tube fitting brands.
