FITOK Sanitary Flange Fittings (Fractional Tube)
SKU:
Brand: FITOK
Category: Fittings and Accessories › Instrumentation Tube Fittings › Flange & Weld Fittings
Tags: Fitok, Flange Fitting, Pipe Fitting
FITOK Sanitary Flange Fittings — 316/316L stainless steel compression double-ferrule tube fittings (Fractional Tube), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as publi...
Contact us for pricing
This product requires a custom quote
Port 1 Size
Port 2 Size
Quantity
Description
FITOK Sanitary Flange Fittings — 316/316L stainless steel compression double-ferrule tube fittings (Fractional Tube), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as published in FITOK's 6D dimensional catalog; the material/series prefix (e.g. 'SS-' for 316 stainless) is applied by FITOK at order entry and is not included in the source catalog data.
Available Variants & Specifications
| Ordering No. | Port 1 Size | Port 2 Size | L (Length) | B (Thread) | C (Depth) | E (Min Orifice) | F (Body Hex) | J | G (Nut Hex) |
|---|---|---|---|---|---|---|---|---|---|
SS-SFF-FL16-SC16 |
1 | 1 | 1.91(48.5) | 0.87(22.1) | 1.23(31.2) | 0.87(22.1) | 1.37(34.9) | 1.98(50.4) | 1.50(38.1) |
SS-SFF-FL16-SC32 |
1 | 2 | 2.49(63.2) | 1.37(34.8) | 1.23(31.2) | 0.88(22.4) | 2.75(69.9) | 2.52(64.0) | 1.50(38.1) |
SS-SFF-FL4-SC12 |
1/4 | 3/4 | 1.57(39.9) | 0.62(15.7) | 0.60(15.2) | 0.19(4.8) | 1.00(25.4) | 0.98(24.9) | 0.56(14.3) |
SS-SFF-FL4-SC16 |
1/4 | 1 | 1.57(39.9) | 0.87(22.1) | 0.60(15.2) | 0.19(4.8) | 1.37(34.9) | 1.98(50.4) | 0.56(14.3) |
SS-SFF-FL4-SC24 |
1/4 | 1 1/2 | 1.57(39.9) | 1.37(34.8) | 0.60(15.2) | 0.19(4.8) | 1.37(34.9) | 1.98(50.4) | 0.56(14.3) |
SS-SFF-FL4-SC8 |
1/4 | 1/2 | 1.57(39.9) | 0.37(9.4) | 0.60(15.2) | 0.19(4.8) | 1.00(25.4) | 0.98(24.9) | 0.56(14.3) |
SS-SFF-FL6-SC12 |
3/8 | 3/4 | 1.63(41.4) | 0.62(15.7) | 0.66(16.8) | 0.28(7.1) | 1.00(25.4) | 0.98(24.9) | 0.69(17.5) |
SS-SFF-FL6-SC16 |
3/8 | 1 | 1.63(41.4) | 0.87(22.1) | 0.66(16.8) | 0.28(7.1) | 1.37(34.9) | 1.98(50.4) | 0.69(17.5) |
SS-SFF-FL6-SC24 |
3/8 | 1 1/2 | 1.63(41.4) | 1.37(34.8) | 0.66(16.8) | 0.28(7.1) | 1.37(34.9) | 1.98(50.4) | 0.69(17.5) |
SS-SFF-FL6-SC8 |
3/8 | 1/2 | 1.63(41.4) | 0.37(9.4) | 0.66(16.8) | 0.28(7.1) | 1.00(25.4) | 0.98(24.9) | 0.69(17.5) |
SS-SFF-FL8-SC12 |
1/2 | 3/4 | 1.74(44.2) | 0.62(15.7) | 0.90(22.9) | 0.41(10.4) | 1.00(25.4) | 0.98(24.9) | 0.87(22.2) |
SS-SFF-FL8-SC16 |
1/2 | 1 | 1.74(44.2) | 0.87(22.1) | 0.90(22.9) | 0.41(10.4) | 1.37(34.9) | 1.98(50.4) | 0.87(22.2) |
SS-SFF-FL8-SC24 |
1/2 | 1 1/2 | 1.74(44.2) | 1.37(34.8) | 0.90(22.9) | 0.41(10.4) | 1.37(34.9) | 1.98(50.4) | 0.87(22.2) |
SS-SFF-FL8-SC8 |
1/2 | 1/2 | 1.74(44.2) | 0.37(9.4) | 0.90(22.9) | 0.37(9.4) | 1.00(25.4) | 0.98(24.9) | 0.87(22.2) |
Additional Details
Instrumentation tube fitting for high-pressure, leak-tight, vibration-resistant connections in process, analytical, and instrumentation piping systems. Interchangeable in form, fit and function with other major compression tube fitting brands.
Additional Information
Length
6 cm
Width
4 cm
Height
4 cm
Weight
0.1 kg
Specifications
Material
316/316L Stainless Steel (Ni content >= 28.5%)
Connection Style
Compression, double-ferrule tube fitting (FITOK 6D Series)
Standard / Certification
Tested to ASTM F1387; dimensionally interchangeable with other major compression tube fitting brands
Pressure Rating
Rated to the maximum working pressure of the mating FITOK tubing (fitting is not the pressure-limiting component)
Tube Type
Fractional Tube
Max working pressure
6000 psig psig
Operating temperature
-28 to +204 °C °C
FITOK Sanitary Flange Fittings — 316/316L stainless steel compression double-ferrule tube fittings (Fractional Tube), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as published in FITOK's 6D dimensional catalog; the material/series prefix (e.g. 'SS-' for 316 stainless) is applied by FITOK at order entry and is not included in the source catalog data.
Available Variants & Specifications
| Ordering No. | Port 1 Size | Port 2 Size | L (Length) | B (Thread) | C (Depth) | E (Min Orifice) | F (Body Hex) | J | G (Nut Hex) |
|---|---|---|---|---|---|---|---|---|---|
SS-SFF-FL16-SC16 |
1 | 1 | 1.91(48.5) | 0.87(22.1) | 1.23(31.2) | 0.87(22.1) | 1.37(34.9) | 1.98(50.4) | 1.50(38.1) |
SS-SFF-FL16-SC32 |
1 | 2 | 2.49(63.2) | 1.37(34.8) | 1.23(31.2) | 0.88(22.4) | 2.75(69.9) | 2.52(64.0) | 1.50(38.1) |
SS-SFF-FL4-SC12 |
1/4 | 3/4 | 1.57(39.9) | 0.62(15.7) | 0.60(15.2) | 0.19(4.8) | 1.00(25.4) | 0.98(24.9) | 0.56(14.3) |
SS-SFF-FL4-SC16 |
1/4 | 1 | 1.57(39.9) | 0.87(22.1) | 0.60(15.2) | 0.19(4.8) | 1.37(34.9) | 1.98(50.4) | 0.56(14.3) |
SS-SFF-FL4-SC24 |
1/4 | 1 1/2 | 1.57(39.9) | 1.37(34.8) | 0.60(15.2) | 0.19(4.8) | 1.37(34.9) | 1.98(50.4) | 0.56(14.3) |
SS-SFF-FL4-SC8 |
1/4 | 1/2 | 1.57(39.9) | 0.37(9.4) | 0.60(15.2) | 0.19(4.8) | 1.00(25.4) | 0.98(24.9) | 0.56(14.3) |
SS-SFF-FL6-SC12 |
3/8 | 3/4 | 1.63(41.4) | 0.62(15.7) | 0.66(16.8) | 0.28(7.1) | 1.00(25.4) | 0.98(24.9) | 0.69(17.5) |
SS-SFF-FL6-SC16 |
3/8 | 1 | 1.63(41.4) | 0.87(22.1) | 0.66(16.8) | 0.28(7.1) | 1.37(34.9) | 1.98(50.4) | 0.69(17.5) |
SS-SFF-FL6-SC24 |
3/8 | 1 1/2 | 1.63(41.4) | 1.37(34.8) | 0.66(16.8) | 0.28(7.1) | 1.37(34.9) | 1.98(50.4) | 0.69(17.5) |
SS-SFF-FL6-SC8 |
3/8 | 1/2 | 1.63(41.4) | 0.37(9.4) | 0.66(16.8) | 0.28(7.1) | 1.00(25.4) | 0.98(24.9) | 0.69(17.5) |
SS-SFF-FL8-SC12 |
1/2 | 3/4 | 1.74(44.2) | 0.62(15.7) | 0.90(22.9) | 0.41(10.4) | 1.00(25.4) | 0.98(24.9) | 0.87(22.2) |
SS-SFF-FL8-SC16 |
1/2 | 1 | 1.74(44.2) | 0.87(22.1) | 0.90(22.9) | 0.41(10.4) | 1.37(34.9) | 1.98(50.4) | 0.87(22.2) |
SS-SFF-FL8-SC24 |
1/2 | 1 1/2 | 1.74(44.2) | 1.37(34.8) | 0.90(22.9) | 0.41(10.4) | 1.37(34.9) | 1.98(50.4) | 0.87(22.2) |
SS-SFF-FL8-SC8 |
1/2 | 1/2 | 1.74(44.2) | 0.37(9.4) | 0.90(22.9) | 0.37(9.4) | 1.00(25.4) | 0.98(24.9) | 0.87(22.2) |
Additional Details
Instrumentation tube fitting for high-pressure, leak-tight, vibration-resistant connections in process, analytical, and instrumentation piping systems. Interchangeable in form, fit and function with other major compression tube fitting brands.
