FITOK Chromatograph Fittings (NPT, Fractional Tube)
Share productSKU:
Click to copyFITOK Chromatograph Fittings — 316/316L stainless steel compression double-ferrule tube fittings (Fractional Tube, NPT Thread), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffi...
Contact us for pricing
This product requires a custom quote
In Stock
Quantity
Add to wishlist
Description
FITOK Chromatograph Fittings — 316/316L stainless steel compression double-ferrule tube fittings (Fractional Tube, NPT Thread), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as published in FITOK's 6D dimensional catalog; the material/series prefix (e.g. 'SS-' for 316 stainless) is applied by FITOK at order entry and is not included in the source catalog data.
Available Variants & Specifications
| Ordering No. | L (Length) | C (Depth) | E (Min Orifice) | G (Nut Hex) | F (Body Hex) |
|---|---|---|---|---|---|
SS-TTT-NFL1-LV |
0.66(16.8) | 0.61(15.5) | 0.01(0.3) | 0.25(6.4) | 0.37(9.5) |
SS-U-NFL1-LV |
1.26(32.0) | 0.61(15.5) | 0.01(0.3) | 0.25(6.4) | 0.25(6.4) |
Additional Details
Instrumentation tube fitting for high-pressure, leak-tight, vibration-resistant connections in process, analytical, and instrumentation piping systems. Interchangeable in form, fit and function with other major compression tube fitting brands.
Additional Information
Length
6 cm
Width
4 cm
Height
4 cm
Weight
0.1 kg
Specifications
General
Material
316/316L Stainless Steel (Ni content >= 28.5%)
Connection Style
Compression, double-ferrule tube fitting (FITOK 6D Series)
Standard / Certification
Tested to ASTM F1387; dimensionally interchangeable with other major compression tube fitting brands
Pressure Rating
Rated to the maximum working pressure of the mating FITOK tubing (fitting is not the pressure-limiting component)
Tube Type
Fractional Tube
Tube Size
1/16 in
Technical Specifications
Impact energy
2.0 J J
Max working pressure
6000 psig psig
Shank type
SDS-PLUS
Operating temperature
-28 to +204 °C °C
FITOK Chromatograph Fittings — 316/316L stainless steel compression double-ferrule tube fittings (Fractional Tube, NPT Thread), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as published in FITOK's 6D dimensional catalog; the material/series prefix (e.g. 'SS-' for 316 stainless) is applied by FITOK at order entry and is not included in the source catalog data.
Available Variants & Specifications
| Ordering No. | L (Length) | C (Depth) | E (Min Orifice) | G (Nut Hex) | F (Body Hex) |
|---|---|---|---|---|---|
SS-TTT-NFL1-LV |
0.66(16.8) | 0.61(15.5) | 0.01(0.3) | 0.25(6.4) | 0.37(9.5) |
SS-U-NFL1-LV |
1.26(32.0) | 0.61(15.5) | 0.01(0.3) | 0.25(6.4) | 0.25(6.4) |
Additional Details
Instrumentation tube fitting for high-pressure, leak-tight, vibration-resistant connections in process, analytical, and instrumentation piping systems. Interchangeable in form, fit and function with other major compression tube fitting brands.
