FITOK Vent Protectors (NPT, Metric Tube)
SKU:
Brand: FITOK
Category: Fittings and Accessories › Instrumentation Tube Fittings › Specialty Fittings
Tags: Specialty Fittings, Fitok
FITOK Vent Protectors — 316/316L stainless steel compression double-ferrule tube fittings (Metric Tube, NPT Thread), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as publis...
Contact us for pricing
This product requires a custom quote
Port 1 Size
Quantity
Description
FITOK Vent Protectors — 316/316L stainless steel compression double-ferrule tube fittings (Metric Tube, NPT Thread), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as published in FITOK's 6D dimensional catalog; the material/series prefix (e.g. 'SS-' for 316 stainless) is applied by FITOK at order entry and is not included in the source catalog data.
Available Variants & Specifications
| Ordering No. | Port 1 Size | L (Length) | F (Body Hex) | B (Thread) | E (Min Orifice) |
|---|---|---|---|---|---|
SS-VPF-NS12 |
3/4 | 1.06(26.9) | 1.06(27.0) | 0.76(19.2) | 0.72(18.3) |
SS-VPF-NS16 |
1 | 1.37(34.8) | 1.37(34.9) | 0.94(23.9) | 0.88(22.4) |
SS-VPF-NS2 |
1/8 | 0.56(14.2) | 0.50(12.7) | 0.38(9.7) | 0.19(4.8) |
SS-VPF-NS4 |
1/4 | 0.78(19.8) | 0.56(14.3) | 0.56(14.2) | 0.28(7.1) |
SS-VPF-NS6 |
3/8 | 0.81(20.6) | 0.69(17.5) | 0.56(14.2) | 0.41(10.4) |
SS-VPF-NS8 |
1/2 | 1.03(26.2) | 0.87(22.2) | 0.75(19.1) | 0.50(12.7) |
Additional Details
Instrumentation tube fitting for high-pressure, leak-tight, vibration-resistant connections in process, analytical, and instrumentation piping systems. Interchangeable in form, fit and function with other major compression tube fitting brands.
Additional Information
Length
6 cm
Width
4 cm
Height
4 cm
Weight
0.1 kg
Specifications
Material
316/316L Stainless Steel (Ni content >= 28.5%)
Connection Style
Compression, double-ferrule tube fitting (FITOK 6D Series)
Standard / Certification
Tested to ASTM F1387; dimensionally interchangeable with other major compression tube fitting brands
Pressure Rating
Rated to the maximum working pressure of the mating FITOK tubing (fitting is not the pressure-limiting component)
Thread Type
NPT Thread
Max working pressure
6000 psig psig
Operating temperature
-28 to +204 °C °C
FITOK Vent Protectors — 316/316L stainless steel compression double-ferrule tube fittings (Metric Tube, NPT Thread), FITOK 6D Series. Ordering numbers shown are FITOK's part-number suffix as published in FITOK's 6D dimensional catalog; the material/series prefix (e.g. 'SS-' for 316 stainless) is applied by FITOK at order entry and is not included in the source catalog data.
Available Variants & Specifications
| Ordering No. | Port 1 Size | L (Length) | F (Body Hex) | B (Thread) | E (Min Orifice) |
|---|---|---|---|---|---|
SS-VPF-NS12 |
3/4 | 1.06(26.9) | 1.06(27.0) | 0.76(19.2) | 0.72(18.3) |
SS-VPF-NS16 |
1 | 1.37(34.8) | 1.37(34.9) | 0.94(23.9) | 0.88(22.4) |
SS-VPF-NS2 |
1/8 | 0.56(14.2) | 0.50(12.7) | 0.38(9.7) | 0.19(4.8) |
SS-VPF-NS4 |
1/4 | 0.78(19.8) | 0.56(14.3) | 0.56(14.2) | 0.28(7.1) |
SS-VPF-NS6 |
3/8 | 0.81(20.6) | 0.69(17.5) | 0.56(14.2) | 0.41(10.4) |
SS-VPF-NS8 |
1/2 | 1.03(26.2) | 0.87(22.2) | 0.75(19.1) | 0.50(12.7) |
Additional Details
Instrumentation tube fitting for high-pressure, leak-tight, vibration-resistant connections in process, analytical, and instrumentation piping systems. Interchangeable in form, fit and function with other major compression tube fitting brands.
